Focus ATLAS 8.7

Original price was: €3,150.00.Current price is: €2,695.00.

ARBON FRAME

SHIMANO GRX600 2X11

NOVATEC 25 ELITE WHEELS

Add to Wishlist
Add to Wishlist
SKU: N/A Categories: , Tag:
Trust Badge Image

Description

  • COMFORTABLE AND AGILE ON ANY TERRAIN

    This light carbon bike is designed for your fast gravel escapes. Due to the combination of long reach and short stem, the ATLAS 8.7 is a rather long bike resulting in a really smooth ride. The front end provides confidence while going downhill. Super short chainstays make the gravel bike playful and agile, which will please all riders who like to tackle each other no matter the surface. To make sure that you can handle this fast bike perfectly, you can adjust the handlebar position according to your needs. The stem is available in six different lengths from 70 to 120 mm and the handlebar height can be changed with special two-piece spacers.

  • VARIOUS OPTIONS TO MOUNT EQUIPMENT

    The ATLAS 8.7 frame offers many options to carry bags comfortably. You can easily attach a bar, saddle, or frame bag. The bike comes with our top tube bag in which you can store essential tools or snacks to eat while pedalling. For bottle cages, the carbon frame provides three more mounting possibilities. One bottle cage can be screwed at the seat tube and two more at the down tube – one above and one below. On top, the three screws on the fork’s left and right side offer two additional mounting points. Here you can install racks for further luggage or bottle cages. With a maximum system weight (bike, rider, and equipment) of 120 kg, this light carbon gravel bike allows you to take lots of stuff with you.

  • MADE FOR FAST GRAVEL ESCAPES

    Thanks to fast-rolling and tubeless-ready 45 mm WTB Riddler tyres and Shimano GRX600 2×11 groupset with gravel-optimised transmission, the ATLAS 8.7 is built to accompany your bikepacking adventures. The wide handlebar with flare provides full control and comfort. The C.I.S. (Cockpit Integration Solution) technology ensures a clean look without any cables in the way when attaching a bar bag. Whether in bad weather conditions or on demanding surfaces, when suffering during steep climbs or going the really long distances – the ATLAS 8.7 fully supports your ride, even to the end of the world.

SPECIFICATION

FRAME
Carbon, disc, C.I.S. integration, press fit BB86, 148×12 mm thru-axle, flat mount 160/160 mm, internal cable routing, Toptube Bag
FORK
Carbon, disc, 110×12 mm thru axle, flat mount 160/160 mm, internal brake cable routing, multiple mounting points
SHIFTER
Shimano GRX ST-RX600, 11-speed
FRONT DERAILLEUR
Shimano GRX FD-RX810
REAR DERAILLEUR
Shimano GRX RD-RX810, 11-speed
CASSETTE
Shimano 105 R7000, 11-speed
CHAIN
Shimano CN-HG601, 11-speed
CRANKSET
Shimano RS520
TRANSMISSION OF DRIVE
vorne: 46/30, hinten: 11-34
HANDLEBAR
FOCUS JD RA85, 31,8 mm, drop: 116 mm, reach: 74 mm, flare: 10°
GRIPS
FOCUS Bartape SL
STEM
FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium
HEADSET
ACROS IS 52/286-IS52/40 (ICR), FOCUS integrated C.I.S.
SADDLE
fi’zi:k Taiga
SEATPOST
Aluminium, 27.2 mm, 0 mm set-back
BRAKE
Shimano GRX BL-RX400, 10-speed
FRONT BRAKE DISC
160 mm
REAR BRAKE DISC
160 mm
WHEELSET
Novatec 25 Elite, 25-622, disc, center lock, front: 110×12 mm, rear: 148×12 mm
WHEEL SIZE
28″
REAR WHEEL SIZE
28″
FRONT TYRE
WTB Riddler, 700 x 45C, folding
REAR TYRE
WTB Riddler, 700 x 45C, folding
WEIGHT
9.6
PERMISSIBLE SYSTEM WEIGHT
120
