Description
The Class 5™ Vibration Reduction System has specially shaped seatstays with a tall, thin, vertically oriented profile that promotes vertical compliance by allowing the seatstays to “flex” outwards on impacts. The horizontally oriented chainstays work to resist torque and maintain a laterally stiff rear end. The seatstays and chainstays lack bridges, furthering the full length of the stays to contribute to flexibility. And a rear thru-axle delivers precise tracking while allowing the seatstays to provide that incredible compliance
We use internal molds at all the main front triangle junctions during layup and curing. This allows for precise control of wall thickness and inner wall smoothness in these areas. This process increases compaction and reduces voids and wrinkles in critical high stress zones. The end result is a top-quality carbon frame that delivers consistent high performance
FRAMESET
- Frame
- Warbird Carbon
- Fork
- Waxwing
- Color
- Light Gray
- Rear Shock
- N/A
DRIVETRAIN
- Front Derailleur
- N/A
- Rear Derailleur
- Shimano GRX RX812
- Cassette
- Shimano M5100, 11–42t, 11-speed
- Chain
- Shimano HG601
- Crankset
- Shimano GRX RX600, 40t -OR- FSA Omega MegaExo, 40t
- Shifter
- Shimano GRX RX600
- Brakes and Rotors
- Shimano GRX RX400 brakes, Shimano RT64 rotors (Center Lock, 160 mm)
COMPONENTS
- Headset
- Cane Creek 40
- Stem
- Salsa Guide
- Handlebar
- Salsa Cowbell
- Grips/Bar Tape
- Anti-Slip Silicone handlebar tape
- Seatpost
- Salsa Guide
- Saddle
- WTB SL8 Medium Steel SL
WHEELS
- Front Wheel
- Shimano RS470 12 x 100 mm hub -OR- Novatec D981SB-CL-12 12 x 100 mm hub, WTB ST i23 TCS rim, 28h
- Rear Wheel
- Shimano RS470 12 x 142 mm hub -OR- Novatec D982TSB-CL-X12 12 x 142 mm hub, WTB ST i23 TCS rim, 28h
- Tires
- Teravail Cannonball 700c x 42 mm, tubeless compatible, Durable casing
WEIGHT
- Complete Bike Weight
- 21 lb 8 oz (56 cm frame)
- Max Tire OD
- 700c: 716mm / 650b: 696mm (Some front derailleurs may reduce tire clearance. Check manufacturer’s specifications to confirm clearance before installing.)
- Design Wheel/Tire Size
- 622 – 32 (700 x 32mm)
- Alternate Wheel/Tire Size
- 622 – 32-45 (700c x 32–45mm / 1.2–1.8”) / 584 – 47-51 (650b x 47mm–51mm / 1.85–2.0”)
- Suspension Fork Length (Travel)
- 436.7mm axle-to-crown (40mm travel)
- Rigid Fork Length
- 405mm
- Fork Offset
- 50mm
- Headset-Upper
- IS41
- Headset-Lower
- IS52
- Seatpost
- 27.2mm
- Seat Collar
- 32.0mm
- Bottom Bracket
- BB86 PressFit
- Crankset
- 1x: 44t max; 2x: 52/36t max, 46/30t minimum
- Rear Brake (Rotor)
- Flat mount 140, 140–160mm, flat mount frame standard 20mm thickness, 27mm bolt length
- Rear Spacing
- 142mm
- Rear Axle
- M12 x 167L, TP = 1.5, TL = 20mm
- Derailleur Hanger
- Hanger 465, QBP# FS2322
- Fender Mounts
- Yes, required fender hardware included
- Rack Mounts
- 165 mm Low-rider compatible. Salsa Down Under rack recommended.
- Water Bottle Mounts
- Frames up to 54cm: 2 in main triangle, frames 56cm and larger: 3 in main triangle
- Downtube Accessory Mount
- Yes, one pair
- Toptube Mounts
- Yes, compatible with Salsa Toptube bag
- Stem Clamp
- Ø28.6mm
- Crown Race
- Integrated SHIS 40, 36° angle
- Front Brake (Rotor)
- Flat mount 160, flat mount rear standard, 35mm thickness, 42mm bolt length
- Front Spacing
- 12 x 100 mm TA
- Front Thru-Axle
- M12 x 120L, TP = 1.5, TL = 12mm
- Three-Pack Mounts
- One mount per fork leg.
- Front Axle
- M12 x 120L, TP = 1.5, TL = 12 mm
