Description
The Class 5™ Vibration Reduction System has specially shaped seatstays with a tall, thin, vertically-oriented profile that promotes vertical compliance by allowing the seatstays to “flex” outwards on impacts. The horizontally oriented chainstays work to resist torque and maintain a laterally stiff rear end. The seatstays and chainstays lack bridges, furthering the full length of the stays to contribute to flexibility. And a rear thru-axle delivers precise tracking while allowing the seatstays to provide that incredible compliance
We use internal molds at all the main front triangle junctions during layup and curing. This allows for precise control of wall thickness and inner wall smoothness in these areas. This process increases compaction and reduces voids and wrinkles in critical high-stress zones. The end result is a top-quality carbon frame that delivers consistent high performance
Our endurance all-road geometry pairs a slack head tube angle with a long offset fork to create high mechanical trail, which increases stability on rough surfaces. 415 mm chainstays make for a bike that’s nimble and responsive but smooth on unpredictable surfaces
This carbon fork with aluminum steerer utilizes a 12 x 100mm thru-axle for true tracking and flat mount brake for quick setup. Most importantly, the fork includes an incredible array of accessory features: Three-Pack mounts accept either water bottle cages or Anything Cages for increased hydration or gear carrying capacity / Mid-blade mounts allow the attachment of our Down Under Low Rider Rack for front pannier use / Internal dynamo hub cable routing means clean cable routing for those upgrading to dynamo front hubs / Fender mounts mean more pleasant riding in rainy weather, allowing you to tack on more training miles
- Frame
- Warroad
- Fork
- Warroad Carbon
- Color
- Black
- Rear Shock
- N/A
DRIVETRAIN
- Front Derailleur
- Shimano 105 R7000
- Rear Derailleur
- Shimano 105 R7000
- Cassette
- Shimano HG700, 11–34t, 11-speed
- Chain
- Shimano HG601
- Crankset
- Shimano RS510, 50/34t
- Shifter
- Shimano 105 R7020
- Brakes and Rotors
- Shimano 105 7070 brakes, Shimano RT54 rotors -OR- Tektro TR160-35A rotors (Center Lock, 160 mm)
COMPONENTS
- Headset
- Cane Creek 40
- Stem
- Salsa Guide
- Handlebar
- Salsa Cowbell
- Grips/Bar Tape
- Anti-Slip Silicone handlebar tape
- Seatpost
- Salsa Guide
- Saddle
- WTB SL8 Medium Steel SL
WHEELS
- Front Wheel
- Shimano RS470 -OR- Alex BRD-50312OF0 12 x 100 mm hub, WTB ST i21 TCS 700c rim, 28h
- Rear Wheel
- Shimano RS470 -OR- Alex BRD-50812M0B 12 x 142 mm hub, WTB ST i21 TCS 700c rim, 28h
- Tires
- Teravail Rampart 700c x 32 mm, Light & Supple casing, tubeless-ready
WEIGHT
- Complete Bike Weight
- 20 lb 12 oz (56 cm frame)
- Tire Size Range for 622 / 29″ Wheels
- 28–35mm (1.1–1.4″)
- Tire Size Range for 584 /27.5″ Wheels
- 47mm (1.85″)
- Tire Size Range for 559 / 26″ Wheels
- NOT COMPATIBLE
- Maximum Wheel/Tire Diameter**
- Ø698mm (27.4″) (Some front derailleurs may reduce tire clearance. Check manufacturer’s specifications to confirm clearance before installing.)
- Minimum Wheel/Tire Diameter***
- Ø684mm (26.9″)
- Rigid Fork Length
- 390mm
- Fork Offset
- 51mm
- Front Brake (Rotor)
- 160mm, flat mount rear standard, 35mm thickness, 42mm bolt length
- Headset-Upper
- IS41
- Headset-Lower
- IS47
- Seatpost
- 27.2mm
- Seat Collar
- 32.0mm
- Dropper Compatible (Routing)
- Internal, when not running front derailleur
- Front Derailleur Mount
- 06-001369
- Bottom Bracket
- BB86 Pressfit
- Crankset (Max Ring)
- 1x crankset: 48t max, 2x crankset: 52/36t max
- Rear Brake, (Rotor)
- 140–160mm, flat mount frame standard 20mm thickness, 27mm bolt length
- Rear Spacing
- 142mm
- Rear Axle Size
- M12 x 167L, TP = 1.5, TL = 20mm
- Derailleur Hanger
- Hanger 465, QBP# FS2322
- Fender Mounts
- Yes, required fender hardware included
- Frame Rack Mounts
- Yes, universal rack rear compatible, Salsa Post-Lock seat collar required, Salsa Wanderlust Rack recommended
- Water Bottle Mounts
- Frames up to 54.5cm: 2 in main triangle, frames 56cm and larger: 3 in main triangle, 1 under the down tube
- Toptube Mounts
- Yes, compatible with Salsa Toptube bag
- Downtube Accessory Mounts
- Yes, one pair
- Stem Clamp
- Ø28.6mm
- Crown Race
- Integrated SHIS 33, 45° angle
- Front Spacing
- 100mm
- Front Thru-Axle
- M12 x 120L, TP = 1.5, TL = 12mm
- Three Pack Mounts
- One mount per fork leg
- Fork Rack Mounts
- 165mm low-rider compatible, Salsa Down Under Rack recommended
