Description
Highlights
— 6061 T6 hydroformed, multi-butted alloy frame
— Lightweight straight bladed 6061 alloy fork
— Shimano GRX 2×10 mechanical transmission + hydraulic disc brakes
— 2×10 transmission (40-46T chainring x 11-36T cassette)
— 700x40mm Schwalbe G-ONE BITE TL-Easy tubeless ready tyres
— Full bottle, mudguard and bikepacking mounting points
Why Dean?
Lightweight, responsive, with more gears and frame sizes than our SRAM-geared single chainring gravel bikes, our latest Dean is a great choice for riders looking for an outstanding blend of value, versatility, and performance. The Dean won’t just survive but thrive wherever your ride takes you.
Features & Equipment
With its proven trail-taming handling it’s got the edge when the road stops, too. The same ride anywhere mountain bike (MTB) inspired handling as the rest of our gravel range – together with wide rims and tyres – are a license to leave those roads far behind and head over the hills, into the forests and down unknown trails. And when you do, the reinforced Schwalbe tyres, 2×10 Shimano GRX gears and brakes – together with full bottle, rack and bikepacking mounts – mean the Dean is a fast, efficient and super tough all-rounder. Sealed cable ports and masses of mud clearance, together with being fully mud-guard ready – just add our own Whyte mudguards all combine to ensure that bad weather will never hold you back.
Specifications
SPECIFICATION | |||
---|---|---|---|
COLOUR | Matt Moss Olive/Burnt Orange | CASSETTE | SunRace CSMS1, 11-36, 10 Speed |
FRAME | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Tapered Head Tube, Custom Drawn, Chainstay Flat Mount 160mm Disc Mount, BBX Cable Routing | CHAIN | SunRace CN10, Black, 10 Speed |
FORK | Whyte Straight Bladed 6061 Alloy, Tapered Alloy Steerer, Internal Cable Routing, Flat Mount Dropouts, 12mm x 100mm Stealth Thru Axle, Eyelets for Mudguards | CRANKSET | Whyte, Forged Cranks, 2pcs, Super Compact Double 30-46t, 10 Speed, 170mm |
REAR SHOCK | N/A | BOTTOM BRACKET | BSA, Cartridge Bearings, 68mm |
HEADSET | FEMIMIN H889B, Integrated Road, 1 1/2″ Lower and 1 1/8″ Upper Sealed Cartridge Bearings | SEATPOST | Whyte 6061 Alloy, 20mm Offset, 27.2mm x 350mm, 2 Bolt Clamp |
REAR HUB | Alloy, Double Sealed Cartridge Bearings, 12mm x 142mm Thru Axle, Centre-Lock, 32 Hole | SADDLE | Whyte Custom |
FRONT HUB | Alloy, Double Sealed Cartridge Bearings, 12mm x 100mm Thru Axle, Centre-Lock, 32 Hole | HANDLEBAR | Controltech, 6061 Alloy, Gravel/Road compact drop, 10mm riser bar, 31.8mm x 420mm 48cm, 440mm 50cm, 460mm 52&54cm, 480mm 56&58cm |
SPOKES | 2.0mm, PG, Black Stainless, Brass Nipples | STEM | Whyte Alloy, +-7° Rise, 48/50cm 60mm, 52cm 70mm, 54cm 80mm, 56/58cm 90mm |
RIMS | Whyte RG-7, Tubeless Ready, 32 Hole | GRIPS | Whyte Anti Slip, Cross Bar Tape |
TYRE | Schwalbe G-ONE BITE, 700 x 40c, TL-Easy with RaceGuard Puncture Protection | BRAKES FRONT | Shimano GRX BR-RX400, 160mm Flat Mount, Internal Routing |
SHIFT LEVERS | Shimano GRX ST-RX400, 10 Speed | BRAKES REAR | Shimano GRX BR-RX400, 160mm Flat Mount, Internal Routing |
FRONT MECH | Shimano GRX RD-RX400, 10 Speed | BRAKE LEVERS | Shimano GRX ST-RX600, Hydraulic |
REAR MECH | Shimano GRX RD-RX400, Shadow Plus, 10 Speed | PEDALS | Fibre Reinforced Composite Platform |
WEIGHT | 11.4 Kg |
